EZ Access Modular Entry Ramp Model TMER

Product Specifications

• The TRANSITIONS Modular Entry Ramp is strong, lightweight, and safe for all users. By combining extensions the Modular Entry Ramp can reach seven different heights.

  SPECIFICATIONS	TMER1	TMER1.5	TMER2	TMER3	TMER4	TMER5	TMER6
  Made of aluminum	√	√	√	√	√	√	√
  Slip-resistant surface	√	√	√	√	√	√	√
  Modular design	√	√	√	√	√	√	√
  Usable size (in) ( H x L x W )	1 x 6.5 x 34	1.5 x 9.5 x 34	2 x 12 x 34	3 x 17 x 34	4 x 22.25 x 34	5 x 27.5 x 34	6 x 32.75 x 34
  Weight ( lbs.)*	3	5	5.5	8	11	15	20
  Weight capacity (lbs)	700	700	700	700	700	700	700
  For wheelchairs & Scooters	√	√	√	√	√	√	√
  Ramp Usage guidelines **	.75" - 1.25" rise	1.25" - 1.75" rise	1.75" - 2.25" rise	2.75" - 3.25" rise	3.75" - 4.25" rise	4.75" - 5.25" rise	5.75" - 6.25" rise

  *  Weights are approximate and may vary.
  ** Consult your equipment's owner guide for proper degree of incline. Never exceed its recommendations.
